The sharpness of the print and vividness of the ink, create a depth in the images that brings the print to life.
Gladi8tor HS includes all the Gandy features of its previous version. To give you a recap, these are:
– NanoDot technology gives sharper prints and smoother color scale.
– Head placement, innovated by Gandy, which avoids the process of aligning print heads, as our laser precision prearranges them in line.
– Crash Sensors that stop for any object (even the smallest ones), to
save print heads from any damage.
– Static Bars to work in dry environments and allow prints to stay sharp.
– Automatic head cleaning & wiping station.
– Graphical User Interface (GUI) with a simple touch-and-drag system.
– Cutting-edge vacuum table to hold uneven materials flat.
– Automatic head height adjustment for different materials.
– Integrated camera, to assist in case of remote service & problem
resolution
– High-powered vacuum table can hold down heavy or uneven material.

A conqueror of the dream through print.

The Gladi8tor HS has kept and finetuned all the features’ customers came to love in the original Gladi8tor whilst also making room for new features that lead to higher speeds, efficiency and print quality. As in the norm with Gandy Digital, all new features have been developed completely in house to pass our strict quality control measures to ensure our printers are able to perform consistently & accurately. The new features below are unique to the Gladi8tor HS include:
1. 3-Row Kyocera Print Heads per color: Enhanced print head configuration allows for a seamless consistent print.
2. Busygoesawayswiftly:The3Kyoceraheadsalsomeanhigher speeds. Busy prints get done in 40 seconds or less (over 90 boards per hour), and solid dark colors are ready in just over a minute (40 boards per hour).
3. One Touch Vacuum & Print: Conveniently placed to start prints, as the one-touch buttons are time-savers on their simplicity and accessibility. 4. UltrasonicSensor:Seetheexactamountofinkthat’sbeingapplied,
as the sensor delivers a precise measurement of ink levels to the GUI.

Print driver specifications

If you are a raster image process (RIP) manufacturer and would like to add the Pred8tor to your Grand Format print driver list please contact: printdriver@support.gandydigital.com for further details. With 30+ years of digital printing technology and proven track record of consistently being at the forefront of the Large Format Digital Print Industry, you’ll want to see for yourself why we lead the way.

The Fascin8tor is the new development based on the tried and true technology from the Pred8tor and Domin8tor which have been coming off the production line at Gandy Digital’s factory in Canada for over 4 years. The Fascin8tor will have the same high resolution, giving exceptional value that just got better with the Roll to Roll introduction.

Gandy re-invents the UV Roll to Roll and brings innovation to reality, introducing the all new Fascin8tor UV Roll to Roll printer giving high quality prints never achieved before at dramatically increased speeds.

The Fascin8tor is the new development based on the tried and true technology from the Pred8tor and Domin8tor which have been coming off the production line at Gandy Digital’s factory in Canada for over 4 years. The Fascin8tor will have the same high resolution, giving exceptional value that just got better with the Roll to Roll introduction.

The new Fascin8tor comes with 3 main options. The first offering 4 color and white, the second giving smooth 6 color (CMYK&LM&LC) quality plus double white solving the white density hurdle. Or double CMYK for twice the speed making the Fascin8tor the fastest printer in its category topping 240sqm. We guarantee that you will be surprised with the quality of the samples printed at 240sqm

The Fascin8tor is a True Roll to Roll UV printer with a vacuum top print plate allowing the ability to print many materials and achieve high quality results. The Fascin8tor also comes in 2 print width sizes. The Fascin8tor 3300 has a print width of 3.3m (10ft 10in) and the Fascin8tor 5000 has a print width of 5m (16ft 5in). The Fascin8tor has a heavy industrial design to handle hours of printing without any interruptions.

Print quality and speed on the Fascin8tor is driven by the inline ‘Blade’ print head configuration system, printing 25.4cm (10 inch) wide swath using 6-picoliter variable dot Ricoh print heads. This system eliminates head to head alignment and gives incredible sharp images.

The Fascin8tor using the blade system allows from 4 to 8 blades to print with accuracy either with higher quality smoother photographic images or with dramatically higher speeds. The Fascin8tor also gives great flexibility that allows you to start with a 4 color system and upgrade easily to 6 color or double speed. Call us to discuss all the options.

You can easily print materials with different thicknesses as the head height adjusts automatically without the need to manually check it (maximum media thickness 50mm / 2”).

The new ‘layered’ printing option makes printing multi-layered colored images and white, simple with a onetime setup and print process. Now you can do backlit images sandwiching white or doubled sided banners with white and black sandwiched between images.

Cleaning is much easier with the fully automated built-in head blotting system, no need to wipe by hand.

Operation of the Fascin8tor is simple with Gandy Digital’s own touch and drag GUI (Graphical User Interface). This is a true mobile operation device enabling step and repeat, rotate, delete ripped images, create jobs allowing interactive trouble shooting via online diagnostic. Profiles and software can also be updated with the online system.

Gandy Digital has a Crash sensor available on the Fascin8tor that truely protects printheads not only against large objects but also against film that can get under the printhead carriage. This option is a true working innovation. You can also get a Static bar to eliminate static allowing smoother prints even if the weather is not the most favorable.

The Fascin8tor options include slitters and even a sheeter allowing to slit and sheet so no extra work after the printing process. The Fascin8tor also comes with a Multi Roll option where you can print different roll widths securely at the same time giving the same high quality results at high speeds.

Gandy Digital has innovated a UV ink that gives excellent adhesion to many plastics including polyethylene films. And on top of that ink usage is minimum making your production costs the lowest with the Fascin8tor.

Gandy Digital’s Fascin8tor is the most advanced and groundbreaking Grand Format Digital Printer in the industry today.

We are the leader of innovative digital printing technology and have a proven track record.

See for yourself and book a demo with one of our representatives or visit www.GandyDigital.com for more details.

The ‘Domin8tor’ (8 blade) is a True UV flatbed with a large 2m x 3.05m (78” x 120”) print area. The ‘Domin8tor’ will print ultra high resolution photographic quality.
Color configuration: C,M,Y,K,LtC,LtM,white,clear / (white,white). – 8 blades.

Sectional vacuum zones.

Rips

The Domin8tor works with all major suppliers of RIP software intergrating seamlessly with your existing production department workflow.
Please contact the RIP manufacturer for options, support and pricing.

Print driver specifications

If you are a raster image process (RIP) manufacturer and would like to add the Domin8tor to your Grand Format print driver list please contact: printdriver@support.gandydigital.com for further details.

With 30+ years of digital printing technology and proven track record of consistently being at the forefront of the Large Format Digital Print Industry, you’ll want to see for yourself why we lead the way.

Gandy Digital is glad to introduce the Termin8tor S. With all the features used for the successful Termin8tor and more! Termin8tor S is a roll-to-roll printer, perfect for a large scale of applications and goes up to 375sqm/h.There is a sharp print quality using Starfire print heads, staggered in 3 rows for big volume output.

Using the GnTek recirculation solution, the Termin8tor S is composed out of a GZ Negative pressure recirculation system with a compensation function which perfectly uses the positive aspects of the Starfire head, assuring solid ink delivery, minimizing downtime and minimizing maintenance.
The Termin8tor S is available in 3.2m model. The Termin8tor S printer allows you to print on flexible substrates as banners, frontlit, backlit and many more.

With an innovative separating taking up system, the Termin8tor S can dry the printing thoroughly during high speed printing using the IR drier. To increase the production time even more, an additional roll has been added to decrease switching time.

To insure the best quality during high speed printing, pre, mid, post and extended heaters are being used. Also the IR drying system is used. Synchronization IR drying prevents the prints over-burnt and saves energy.

Termin8torS printer is an industrial printer and is built that way! Enhanced aluminum beam, beam holders and body frame assure extreme high speed printing & long running life.

See for yourself and book a demo with one of our representatives or visit www.gandydigital.com for more information.

The Gandy NextJet platform offer our newest dye sublimation textile printer platform based on the superfast, high resolution Kyocera head technology. NextJet Paper 3300 prints on transfer paper only, so you only need to profile once for your paper and not for every fabric that is run through the printer. Spend less time profiling and more time printing. NextJet Paper also offers the lowest total cost of ownership in the industry through a combination of high pigment ink, lightweight paper and low cost of entry.

FAST AND ACCURATE
You can only print as fast as the ink can dry. That’s why the NextJet Paper 3300 uses advanced technology with multiple drying elements for fast and even linear drying. It heats below the platen to warm the material while protecting the print heads. After ink is applied, the media then passes 99 cm of linear drying area with adjustable temperature settings. This drying process allows the ink to dry by the time the media reaches the take-up roll, even when printing at top print speeds.

PRINTHEAD TECHNOLOGY
State-of-the-art Kyocera print heads with a 4 pL native drop size result in high-speed, true grey- scale fabric printing. These heads offer the fastest dye sublimation printing and smallest drop size in the digital textile print industry.
The NextJet Paper 3300 can be configured as 2 or 4 heads per channel and is field upgradable when you are ready to increase your speed. Outfitted with the 4-head configuration, NextJet Paper 3300 is almost 2x the speed of many of the most popular dye sublimation printers on the market today.

NEXTJET 1.1 INK
Achieve a brilliant color gamut with super rich blacks, a heavy pigment load and excellent grey-scale. The vibrant, water-based inks pass all OEKO-TEX® Standard 100 Certifications. They are produced in an ISO 9001 facility with strict quality control and provide the lowest cost per print in the industry for an industrial dye sublimation printer.

VARIABLE DROP PRINTING
NextJet 3300 printers utilize Kyocera variable drop grey-scale heads that produce drops of varying colors and sizes within a single image file, marrying the best combination of the image quality that comes with small drop sizes and the productivity associated with large drop printing.Using only 4 colors, the precision of the Kyocera heads provides fine, detailed text and superior image quality, especially in gradients and mid-tones. Because NextJet does not require light colors, users realize up to a 50% reduction in ink usage, further reducing their cost of operation and increasing their profit margins.

Based on a completely new developed system, the Gandy NextJet Direct Series new family of direct-to-fabric digital printers provides a complete solution that enables printing directly onto polyester fabrics and other fabric substrates with flawless results. The system features precision media handling components and an advanced on-board sublimation unit that together ensure outstanding image quality and rich, saturated colors for flags, banners, textiles, and soft signage that maintain their natural drape and texture. Industrial built digital textile dye sublimation printer with on-board true calander with pressure, timing and heat. Two print widths available: 3.3m and 5.3m. Water-based inks. State-of-the-art Kyocera 4pL variable drop print heads.

PRINT ON MESH FABRICS
Our new solution is designed to easily print on open mesh fabrics such as flag material and sports textiles without marking the backside of the fabric with “blow-by” ink. The especially designed ink trough with sponge and pad absorbs any ink that passes through the fabric.

DESIGNED TO BE RUGGED AND RELIABLE
Gandy NextJet direct-to-fabric printing system combines trusted performance and reliability with award winning innovative design and print quality.

NEXT
Specifically designed for Gandy Direct Series, the InLine Cutting System dramatically increases its capabilities.The production process is made easier and faster by cutting fabric on the vertical axis. The system uses cold knife technology to make sharp flawless cuts. The InLine Cutting System can be stopped or paused without creating defects in the printed fabric which is a significant advantage over traditional hot knife systems. Now with the addition of the InLine Cutting System, you can also cut the fabric, while keeping it contained within the footprint of a single compact roll-to-roll printer system. It features:

– Rotating Steel Cutter Bar driven by precision 24VDC motor
– Heavy Duty construction for industrial use Cold Knife Technology
– Adjustable knives, 6 included with the 3.3m version, 8 included with 5.3m version
– Compact footprint, mounts to OBS unit resulting in no increase in printer size
– Includes all accessories necessary for installation

MEDIA HANDLING SYSTEM
The engineered system features two precision stepping motors and synchronized dancing rollers that automatically fine tune the media feeding process to ensure precise movements with every pass of the print head. Also a special cork covered cylinder can be activated when printing on stretchable media such as Lycra, Spandex and other sports textiles.

PRINTHEAD TECHNOLOGY
State-of-the-art Kyocera print heads with a 4 pL native drop size result in high-speed, true grey-scale fabric printing.These heads offer the fastest dye sublimation printing and smallest drop size in the digital textile print industry.
The NextJet Direct Series can be configured as 2 or 4 heads per channel and is field upgrad- able when you are ready to increase your speed. Outfitted with the 4-head configuration. NextJet Direct Series is almost 2x the speed of many of the most popular dye sublimation printers on the market today.

NEXTJET 1.1 INK
Achieve a brilliant color gamut with super rich blacks, a heavy pigment load and excellent grey- scale.The vibrant, water-based inks pass all OEKO-TEX® Standard 100 Certifications. They are produced in an ISO 9001 facility with strict quality control and provide the lowest cost per print in the industry for an industrial dye sublimation printer.

VARIABLE DROP PRINTING
NextJet Direct Series printers utilize Kyocera variable drop grey-scale heads that produce drops of varying colors and sizes within a single image file, marrying the best combination of the image quality that comes with small drop sizes and the productivity associated with large drop printing. Using only 4 colors, the precision of the Kyocera heads provides fine, detailed text and superior image quality, especially in gradients and mid-tones. Because NextJet does not require light colors, users reduce up to a 50% reduction in ink usage, further reducing their cost of operation and increasing their profit margins.

From high-tech digital printers to drying systems, from proprietary software to consumables, Aleph is able to offer integrated printing solutions to their clients in order to become a partner for their success. Thanks to its customer-centered approach, cost-effective solutions and the expert service, Aleph aims to ensure the clients the maximum return on their investments.

Aleph is committed to conserving water, energy, and other natural resources utilized in our products and services, across the supply chain from procurement through production, distribution, end use and product disposal.

Visit the Aleph website

Visit the Kimla website

Introducing the New kre8tor 3.2m/5m high speed UV printers
achieving up to 190sqm/hr (2040 sqft/hr) with the sharpest print
quality up to 1800dpi resolution, utilizing Kyocera variable dot
printheads with a native droplet of 3.5picoliter. A perfect combination
of precision, speed, stability!

Available in 3.2m (10’6”) and 5m (16’5”) with pricing comparative to
smaller size models. The kre8tor 3.2m/5m UV printer allows you to print
kre8tor3.2m/5m Roll to Roll printer also has many power levels of UV lamps for
curing di erent materials.

of a wide range of media including thin media while allowing for
continuous printing at high speed.

Gandy has introduced high density UV ink for use on the kre8tor 3.2m/5m
printers which useslessink persquare meter(orsquare foot). For example
on the 4 color mode,over 200 sqm/l (2150 sqft/l) is produced, which makes
your print cost the lowest in the industry.

See for yourself and book a demowith one of ourrepresentatives or visit
www.GandyDigital.com for more details.
